Hotchkis Sport Suspension Upper A-Arms 1963-1972 Chevrolet C-10 / GMC C15/C1500 11390U

Hotchkis Sport Suspension 11390U 1963-1972 C-10 Tubular Upper Control Arms. Install the Hotchkis Tubular Upper A-Arms on your 63-72 C-10 Pickup and gain vastly increased handling and control. These TIG-welded geometry corrected bolt-on arms offer premium quality construction and improve camber gain dramatically increasing handling performance. Added caster improves high speed stability while the smooth operating Delrin bushings in the 4130 billet cross shaft allow the arms to move through their travel easily. Finished in gloss black powder coat the arms are ready to install and are complete with premium ball joints and integrated droop stops. Easy installation with no vehicle modifications required. For even greater handling improvements combine with the Hotchkis Sport Suspension Tubular Lower A-Arms. Features: Improved negative camber gain dramatically improves handling performance. Increased Caster for high speed stability. Smooth operating greasable Delrin Bushings Light weight Strong 1-1/8 in. TIG-welded tubing. TIG-welded laser cut Reinforcement Gussets. 4130 offset Cross Shaft for improved negative camber gain. Includes high quality Ball Joints. Benefits: Improves handling stability and steering response. Improved camber gain; dramatically improves handling performance. Increased caster for high speed stability. Increased structural rigidity over stock due to TIG welding and laser cut support plates. Delrin bushings allow smooth operation with minimal deflection throughout travel range. Integrated droop stop for proper suspension travel. PROUDLY MADE IN THE USA.

Attributes:

• GTIN: 00810361030383
• Brand Name: Hotchkis Performance

Extended Information:

• Country of Origin: United States
• Emissions : Released
• Life Cycle Status: Available To Order

Packing Information:

• Quantity of Each: 1
• Package UOM: EA
• Dimension: 20.75 x 14 x 5 inches
• Weight: 23 lb
