McLeod Bellhousing:Aluminum With Titanium Liner:FORD:SFI 6.1:With Block Plate. 8560T

McLeod aluminum bellhousings are the gold standard when it comes to accuracy and compact performance. They're constructed of CNC-machined spun aluminum—with a narrow body design for lightness, and a titainium inner liner for added strength and protection. These bellhousing come with a removeable inspection cover to help aide in clutch adjustment between rounds. They come in two different configuations, SFI rated with a steel block plate that gives the bellhousing its SFI 6.1 rating. We also offer a Non- SFI rated version for those customers looking for a light weight bellhousing, but not concerned with a SFI rating so these units do not come with a steel block plate.

Attributes:

• GTIN: 00887753315830
• Brand Name: McLeod
• Make: Ford
• Engine: 1964-1995 SBF
• Trans Type: Borg Warner T-5
• Flywheel Fitment: Fits 164 Tooth Flywheel Only
• Bellhousing Material: Aluminum With Titanium Liner
• Block Plate Included: Yes
• SFI Approved: Yes
• Stock Collar I.D.: 4.850In.
• NOTE:: This bell housing has a very specific fitment requirement. It requires a SBF with a flywheel that has a 164T Ring Gear and a transmission with a Borg Warner T-5 mounting pattern and input-shaft length. Aftermarket transmissions such as G-Force, Liberty Gears, Rockland Standard Gear, Astro Performance will work as long as the transmission fits the parameters listed above. Call McLeod Tech for further info 714-630-2764.

Extended Information:

• Country of Origin: United States
• Emissions : Released
• Life Cycle Status: Available To Order

Packing Information:

• Quantity of Each: 1
• Package UOM: EA
• Dimension: 7 x 19 x 20 inches
• Weight: 20 lb
