Bilstein Shock Absorbers 24-296946

Bilstein SMX Series shock absorbers are specifically designed for motorsports applications that mandate the use of stock mount (OE) suspension components. Designed using 46mm monotube technology, the shocks are available in a variety of damping options including dry kit designed specifically to provide the best options for a variety of race track types and conditions. Built in the USA with precision components and top quality controls, the SMX Series shocks deliver Bilstein’s famous fade-free performance and consistency in a factory-mount package that championship winning racers demand.

Attributes:

• GTIN: 00651860847733
• Brand Name: Bilstein
• Body Material: Steel
• Series: SMX Series
• Body Design: Stock Mount Smooth Body
• Collapsed Length (MM): 329.0
• Piston Type: Linear
• Extended Length (MM): 534.0
• Boot Included: No
• Spring Seat Included: No
• Adjustable Damping: Non-Adjustable
• Internal Design: Monotube
• Compression @ 5"/sec: 117
• Valving Identifier: 5 (com/reb)
• Body Diameter (ID): 46mm
• Collapsed Length (IN): 12.95
• Finish: Black Paint
• Extended Length (IN): 21.02
• Rebound @ 5"/sec: 149
• Upper Mount Type: Bar Pin
• Lower Mount Type: Eye

Extended Information:

• Country of Origin: United States
• Emissions : Released
• Life Cycle Status: Available To Order

Packing Information:

• Quantity of Each: 1.0
• Package UOM: EA
• Dimension: 26.8000 x 3.5500 x 3.5500 inches
• Weight: 4.7000 lb
