Canton 15-242TBLK Oil Pan Small Block Chevy 1993-1997 F Body Road Race Pan

CANTON:

Part # CANTON-15-242TBLK
UPC # 00887753712196

$519.00 USD

~~$685.08 USD~~ $519.00 USD

Sale Sold out

Shipping calculated at checkout.

Quantity

Product Description

This black powder coat road race pan is for '86 and newer SBC blocks in '93-'97 F-Bodies. (also fits Impalas) It has a 7-1/2" deep, 12" wide, 8-1/4" long sump for a 6 qt. system capacity. Will work with stock starter. This pan requires one of our pickups.

Triple Trap Door Baffle
Crank Scraper
Built In Screen Windage Tray
1/2" NPT Temperature Bung
Provision for Pan Mounted Dipstick
Magnetic Drain Plug
20mm Fitting for Low Warning Sender

Attributes

GTIN: 00887753712196
Brand Name: Canton
Feature 2: Crank Scraper
Recommended Accessory 5: 20-021 - Bolt-On Pickup for Melling M10555 Pumps
Engine: For S.B. Chevy 1986 and newer blocks with one piece seal
Drain Plug Included: Yes
Dipstick Port: No
Crank Scraper Included: Yes
Capacity: 6 Quart System Capacity
Baffled: Yes
Windage Tray Included: Yes
Stoke: 3.75 inches
Recommended Accessory 7: 88-100T ? SBC 86+ Oil Pan Gasket
Recommended Accessory 6: 22-405 - 20MM Plug for Oil Level Sender Port
Recommended Accessory 4: 20-023 - Pickup for SBC High Volume Oil Pump M155HV with 3/4" Inlet
Feature 3: Bolt in Windage Tray
Recommended Accessory 3: 20-020 - Pickup for SBC High Volume Oil Pump M55HV
Recommended Accessory 2: 20-013 - Pickup for SBC Standard Volume Oil Pump M155 with 3/4" Inlet
Recommended Accessory 1: 20-010 - Pickup for SBC Standard Volume Oil Pumps M55 & M55A
Pickup Included: No
Material: 16 Gauge Steel
Kicked Out: Yes
Hardware Included: No
Gasket or Seal Included: No
Finish: Black Powdercoat
Feature 5: 20mm Fitting for GM Low Oil Warning Sender
Feature 4: 1/2" NPT Temperature Bung
Feature 1: Trap Door Baffle for Oil Control
