HAMBURGER'S PERFORMANCE PRODUCTS FABRICATED ALUMINUM OIL PAN; GM LS ENGINE 1179

• Kickouts For Additional Oil Capacity
• Designed Especially For Installing An LS Engine In Classic American Cars and Trucks
• Fabricated Aluminum Construction
• Includes Gasket, Bolts, Drainplug and Special Pick-Up Tube
• Trap Door Baffling To Control Oil And Maintain Oil At The Pickup Tube

Attributes:

• GTIN: 00086923011798
• Brand Name: Hamburger's Performance
• Baffled: Yes
• Bolts/Studs Included: No
• Crank Shaft Wiper Included: No
• Kicked Out: Yes
• Pickup Included: Yes
• Sump Location: Rear
• Sump Style: Wet Sump
• Windage Tray Included: No
• Capacity: 5-1/2 Qts.
• Depth: 6-1/2 in.
• Dipstick Port: No
• Drain Plug Included: Yes
• Finish Type: Natural
• Fluid Capacity: 5-1/2 Qt
• Material: Aluminum
• Width: 10.50 in.
• Maximum Stroke: 4.25 in.
• Mount Hole Quantity: 15
• Oil Pan Bolts Included: No
• Stroker Clearanced: Yes
• Engine Notes: LS1, LS6, LS2, LS3, LS9, L76, L98, L92, L93, L99, LQ4, LQ9, LSA, and V8 Vortec.
• Finish: Clear Anodized
• Type: Oil Pan
• Kit Type: Oil Pan Only
• Color: Aluminum
• Color/Finish: Machined Aluminum
• Construction: Fabricated Aluminum
• Contents: Oil Pan, Oil Pickup, Gaskets (Bolts not included)
• Engine Manufacturer: Chevrolet
• Engine Oil Cooler Return Fitting: No
• Fastener(s) Included: No
• Gasket Or Seal Included: Yes
• Hardware Included: NO
• IMPORTANT!: This pan is Intended for car or truck use only, and not for Marine applications.
• Installation Hardware Included: No
• Kickout Position: Driver and passenger side
• Mounting Hardware Included: No
• Oil Pan Capacity: 5-1/2 Qt. Capacity
• Oil Pan Finish: Brushed Aluminum
• Oil Pan Material: Aluminum
• Package Contents: Oil Pan, Gaskets, Drain plug, Pickup Tube
• Pan Capacity: 5-1/2 Qts.
• Pickup #: 2525
• Plug Included: Yes
• Replacement Gasket Set: 4336
• Length: 9 in.
• Installation Notes: Not compatible with Factory Windage Tray. Stock windage tray must be removed.
• Notes: Will not fit Corvette.
• Engine: Chevy LS Series
• Product Type: Oil Pans
• Vehicle Use: A-Body (GM) 1964-67

Extended Information:

• Country of Origin: Taiwan
• Life Cycle Status: Available To Order
• Emissions : Released

Packing Information:

• Quantity of Each: 1
• Package UOM: EA
• Dimension: 25.250 x 12.250 x 10.500 inches
• Weight: 8.350 lb
