Hedman Hedders ELITE HEADERS; 1-1/2 IN. TUBE DIA.; 3 IN. COLL.; FULL LENGTH DESIGN 89278

<p>Hedman Hedders has been manufacturing quality headers in the USA since 1954, and they've been manufacturing Ford truck headers decades. Each set uses mild steel, smooth flowing, CNC mandrel bent tubes, that are hand-welded to ensure each pair is identical to the next. Hedman's unique, gasketless ball and socket collector design allows your exhaust system to bolt up to these 351W (5.8L) headers, even if it is not perfectly aligned with the header collectors.</p><p>This set is part of Hedman's ELITE line that uses stout 3/8" flanges, and thicker 14 gauge primary tubes. The heavy-duty construction of HEDMAN ELITE Hedders makes them ideal for high-performance engines, which produce higher exhaust temperatures.</p><p>ELITE models have a MATTE-SILVER ceramic finish that can withstand temperatures up to 1400 degrees F. The coating looks great, and keeps more heat in the tubes, resulting in faster exhaust speeds for improved scavenging, and reduced underhood temperatures.</p><p>These LONG-TUBE headers fit 1980-95 2WD Ford 1/2, 3/4 and 1 ton, and 1982-96 4WD Ford 1/2, 3/4 and 1 ton Trucks and Broncos with a 351W (5.8L) non-E.G.R. engine. The long, smooth-flowing 1-1/2 in. tube design provides superb exhaust flow to let your Ford truck's 5.8L engine breathe easy, and produce loads of horsepower and torque. They fit column-shift automatic and floor-shift manual transmissions, but will not work on lifted trucks, or 4WD models with a Dana 60 front differential.</p><p>Each set includes a pair of gaskets, header flange bolts and collector bolts. No collector gasket is needed.</p><p>Hedman Hedders is so confident in the quality of its headers that these headers are factory backed by a Limited Lifetime Warranty. The ceramic-metallic coating is covered by a 5-year factory warranty, in addition to Hedman's standard lifetime header warranty.</p>

• Heavy-Duty ELITE Header Construction With Thick 3/8 in. Flanges and 14g Primary Tubes To Hold Up To The Added Tortures Of High-Performance and Truck Engines.
• Thermal Coating Keeps More Heat In The Headers To Keep Underhood Temps Down and Protect Against Corrosion.
• Ball & Socket Collector Design requires No Gasket, and Allows For More Exhaust System Misalignment than Old School, Gasket-Style Header Collectors
• Includes All The Necessary Mounting Hardware, Gaskets and Reducers (exhaust adapters)
• Limted Lifetime Warranty On Construction, Five Year Warranty on Factory-Applied Header Coating!
• Proud To Say, Made In The USA, Since 1954!

Attributes:

• GTIN: 00732611892780
• Brand Name: Hedman Hedders
• Reducers Included: Yes
• Air Conditioning: Yes
• Automatic Transmission - Column: Yes
• Automatic Transmission - Floor: No
• Collector Size: 3 in.
• Collector Style: BALL and SOCKET Style (Gasketless)
• Exhaust System Dia: 2-1/2 in.
• Finish: Matte Silver Ceramic-Metallic
• Finish Type: MATTE SILVER Ceramic-metallic coated
• Flange Style: Standard
• Replacement Head Flange Gasket: 27340
• Header Port Shape: Square
• IMPORTANT!: Will Not Fit Vehicles with DANA 60 Front Differential
• Key Feature: NO A.I.R. / NO E.G.R.
• Manual Transmission - Column: No
• Manual Transmission - Floor: Yes
• Material: Mild Steel
• Port Shape: Square
• Power Steering: Yes
• Reducer Outlet Size: 2-1/2 in.
• Special Engine Notes: 351 WINDSOR
• Tube Design: LONG TUBES
• Tube Diameter: 1-1/2 in.
• Tube Length: Long Tubes
• Tube Material Thickness: 14g
• Tube Size: 1-1/2 in.
• Variations: 89276, 98273
• Cylinder Head Port Shape: Square
• Header Finish: Matte Silver Ceramic-Metallic
• Header Material: Mild Steel
• Mounting Hardware Included: Yes
• Primary Tube Diameter (in): 1.50 in.
• Primary Tube Gauge: 14g
• Tuned: No
• Weld-Up: No
• Collector Bolts Included: Yes
• Catalytic Converter(s) Included: No
• Crossover Pipe Included: No
• Motor Mounts Included: No
• Quantity: Sold as a pair.
• Cylinder Head: Stock Profile Heads
• Replacement Gasket: 27340
• Installation Hardware Included: Yes
• with A.I.R. System: No
• Bolts/Studs Included: Yes
• Flange Thickness: 0.375 in.
• Gasket Or Seal Included: Yes
• Header Style: Long Tube
• with EGR: No
• Y-Pipe Included: No
• Collector Attachment: 3 in.
• Header Construction: ELITE Heavy-Duty
• E.O. #: No
• Engine Version: Ford Windsor Block (W)
• Notes: 82-96 Ford F150, F250, F350, Bronco; 2-4WD 351W 5.8L
• Emissions Notes: NOT LEGAL FOR STREET USE ON '75-LATER MODEL YEARS! Legal for off-road use only.
• Collector Diameter: 3 in.
• Tube Style: Long Tubes
• Contents: headers, header gaskets, Reducers (exhaust adapters), header and collector bolts
• Package Contents: Headers, ball and socket reducers (exhaust adapters), gaskets, mounting hardware

Extended Information:

• Country of Origin: United States
• Life Cycle Status: Available To Order
• Emissions : EPA Eligible

Packing Information:

• Quantity of Each: 1
• Package UOM: ST
• Dimension: 39.250 x 18.250 x 9.630 inches
• Weight: 33.000 lb
