Hedman Hedders HEDMAN HEADERS 1982-04 CHEVY/GMC S10/S15 (2WD) LS SWAP HEADERS; 1-1/2 IN. LONG TUBE; 3 IN. BALL/SOCKET COLLECTOR- HTC SILVER CERAMIC COATED 69056

Hedman Hedders HEDMAN HEADERS 1982-04 CHEVY/GMC S10/S15 (2WD) LS SWAP HEADERS; 1-1/2 IN. LONG TUBE; 3 IN. BALL/SOCKET COLLECTOR- HTC SILVER CERAMIC COATED 69056

HEDMAN HEDDERS:

Part # HEDMAN-69056
UPC # 00732611690560

Regular price $1,442.52 USD
Regular price $1,903.00 USD Sale price $1,442.52 USD
Sale Sold out
Shipping calculated at checkout.

Product Description

  • Handcrafted, Mild Steel Construction.
  • Long Tube, Under Chassis Header Design Provides Excellent Top-End Horsepower and Torque.
  • Ball & Socket Collector Design requires No Gasket, and Allows For More Exhaust System Misalignment than Old School, Gasket-Style Header Collectors
  • Includes All The Necessary Mounting Hardware, Gaskets and Reducers (exhaust adapters)
  • Limted Lifetime Warranty On Construction, Five Year Warranty on Factory-Applied Header Coating!
  • Proud To Say, Made In The USA, Since 1954!
  • Under Chassis Design

Attributes:

  • GTIN: 00732611690560
  • Brand Name: Hedman Hedders
  • Air Conditioning: Yes
  • Automatic Transmission - Column: No
  • Automatic Transmission - Floor: Yes
  • Bolts/Studs Included: Yes
  • Catalytic Converter(s) Included: No
  • Collector Attachment: 3 in.
  • Collector Bolts Included: Yes
  • Collector Style: BALL and SOCKET Style (Gasketless)
  • Contents: Headers, gaskets, 3-bolt exhaust adapters, mounting hardware
  • Crossover Pipe Included: No
  • Cylinder Head: Stock Profile Heads
  • Cylinder Head Port Shape: Round
  • Emissions Notes: NOT LEGAL FOR STREET USE ON '75-LATER MODEL YEARS! Legal for off-road use only.
  • E.O. #: No
  • Exhaust System Dia: 2-1/2 in.
  • Finish: HTC Polished Silver Ceramic-Metallic
  • Finish Type: HTC SILVER (polished) Ceramic-metallic Coating
  • Flange Style: Standard
  • Flange Thickness: 0.375 in.
  • Replacement Gasket: 27470
  • Gasket Or Seal Included: Yes
  • Replacement Head Flange Gasket: 27470
  • Header Construction: Standard-Duty
  • Header Finish: HTC Polished Silver Ceramic-Metallic
  • Header Material: Mild Steel
  • Header Port Shape: Round
  • Installation Hardware Included: Yes
  • Motor Mounts Included: No
  • Manual Transmission - Column: No
  • Manual Transmission - Floor: Yes
  • Material: Mild Steel
  • Port Shape: Round
  • Power Steering: Yes
  • Primary Tube Diameter (in): 1.50 in.
  • Primary Tube Gauge: 16g
  • Quantity: Sold as a pair.
  • Reducer Outlet Size: 2-1/2 in.
  • Reducers Included: Yes
  • Tube Design: LONG TUBES
  • Tube Diameter: 1-1/2 in.
  • Tube Length: Long Tubes
  • Tube Material Thickness: 16g
  • Tube Size: 1-1/2 in.
  • Tuned: No
  • Variations: 69050, 69053, 69056
  • Weld-Up: No
  • with A.I.R. System: No
  • with EGR: No
  • Y-Pipe Included: No
  • Drivetrain: 2WD Only!
  • Vehicle Use: Chevy/GMC S10/S15 Family; 1982-04
  • Installation Notes: Requires Trans-dapt Engine Swap Mount Kit 4516 (rubber) or 4530 (all steel)
  • Engine: Chevy LS Series
  • Product Type: Headers
  • Collector Diameter: 3 in.
  • Collector Size: 3 in.
  • Tube Style: Long Tubes
  • Header Style: Long Tube
  • Package Contents: Headers, ball and socket reducers (exhaust adapters), gaskets, mounting hardware

Extended Information:

  • Country of Origin: United States
  • Emissions : Electronically Announced
  • Life Cycle Status: Available To Order

Packing Information:

  • Quantity of Each: 1
  • Package UOM: PR
  • Dimension: 39.000 x 16.500 x 8.250 inches
  • Weight: 37.000 lb
