Hedman Hedders HTC COATED HEADERS; 1-1/2 IN. TUBE DIA.; STOCK COLL.; SHORTY DESIGN 69656

• Handcrafted, Mild Steel Construction.
• The Short Tube Header Design Provides Good Low-End Power, and Provides Excellent Ground Clearance And Component Compatibility.
• Stock-Style Header Collector Bolts Up To The Factory Exhaust Without Modification.
• Includes All The Necessary Mounting Hardware, Gaskets and Reducers (exhaust adapters)
• Limted Lifetime Warranty On Construction, Five Year Warranty on Factory-Applied Header Coating!
• Proud To Say, Made In The USA, Since 1954!

Attributes:

• GTIN: 00732611696562
• Brand Name: Hedman Hedders
• Bolts/Studs Included: Yes
• Flange Thickness: 0.375 in.
• Gasket Or Seal Included: Yes
• Header Style: Short Tube
• Reducers Included: No
• Air Conditioning: Yes
• Automatic Transmission - Column: Yes
• Automatic Transmission - Floor: Yes
• Collector Size: Stock
• Collector Style: Stock Collector
• Contents: Headers, gaskets, header & collector bolts/nuts. Collector donuts not included!
• Emissions Notes: EO# D167-33 (click here for covered vehicles in document on ARB.CA.GOV website)
• Finish: HTC Polished Silver Ceramic-Metallic
• Finish Type: HTC SILVER (polished) Ceramic-metallic Coating
• Flange Style: Standard
• Replacement Head Flange Gasket: 27520
• Header Port Shape: Oval Port
• Manual Transmission - Column: Yes
• Manual Transmission - Floor: No
• Material: Mild Steel
• Port Shape: Oval
• Power Steering: Yes
• Special Engine Notes: VORTEC
• Tube Design: SHORT TUBES
• Tube Diameter: 1-1/2 in.
• Tube Length: Short Tubes
• Tube Material Thickness: 16g
• Tube Size: 1-1/2 in.
• Tube Style: Shorty
• Variations: 69650
• Cylinder Head Port Shape: Oval
• Header Finish: HTC Polished Silver Ceramic-Metallic
• Header Material: Mild Steel
• Mounting Hardware Included: Yes
• Primary Tube Diameter (in): 1.50 in.
• Primary Tube Gauge: 16g
• Tuned: No
• Weld-Up: No
• Catalytic Converter(s) Included: No
• Crossover Pipe Included: No
• Motor Mounts Included: No
• Quantity: Sold as a pair.
• Cylinder Head: Stock Profile Heads
• Replacement Gasket: 27520
• Installation Hardware Included: Yes
• Package Contents: Headers, gaskets, header & collector bolts/nuts. Collector donuts not included!
• with A.I.R. System: No
• with EGR: Yes
• Y-Pipe Included: No
• Collector Attachment: Stock
• Header Construction: Standard-Duty
• E.O. #: Yes
• Collector Gasket Included: No (Requires GM #15093974, or equivalent, exhaust seal)
• Notes: 96-00 Chev. 1/2, 3/4, 1 Ton Truck 2-4WD
• Collector Diameter: Stock
• Exhaust System Dia: Factory hookup
• Reducer Outlet Size: Stock

Extended Information:

• Country of Origin: United States
• Emissions : Released
• Life Cycle Status: Available To Order

Packing Information:

• Quantity of Each: 1
• Package UOM: ST
• Dimension: 20.000 x 13.500 x 8.250 inches
• Weight: 21.000 lb

PDF:

PDF:

69650series-Instructionsheet
