Hedman Hedders HTC COATED HEADERS; 1-3/4 IN. TUBE DIA.; 3 IN. COLL.; SHORTY DESIGN 86511

• Specially Designed To Provide Additional Clearance For Larger, Close-Ratio (Quick Ratio) Steering Boxes
• The Mild Steel, Mid-Length Tube Header Design Provides Significantly More Low and Mid-range Power than Cast Manifolds, and Provide Better Ground Clearance And Component Compatibility Than Long Tube Headers.
• Ball & Socket Collector Design requires No Gasket, and Allows For More Exhaust System Misalignment than Old School, Gasket-Style Header Collectors
• Includes All The Necessary Mounting Hardware, Gaskets and Reducers (exhaust adapters)
• Limted Lifetime Warranty On Construction, Five Year Warranty on Factory-Applied Header Coating!
• Proud To Say, Made In The USA, Since 1954!

Attributes:

• GTIN: 00732611865111
• Brand Name: Hedman Hedders
• Bolts/Studs Included: Yes
• Flange Thickness: 0.375 in.
• Gasket Or Seal Included: Yes
• Header Style: Mid-Length Tube
• Reducers Included: No
• Air Conditioning: Yes
• Automatic Transmission - Column: Yes
• Automatic Transmission - Floor: No
• Collector Size: 3 in.
• Collector Style: Stock Collector
• Emissions Notes: EO# D167-32 (click here for covered vehicles in document on ARB.CA.GOV website)
• Finish: HTC Polished Silver Ceramic-Metallic
• Finish Type: HTC SILVER (polished) Ceramic-metallic Coating
• Flange Style: Standard
• Replacement Head Flange Gasket: 27680
• Header Port Shape: Square
• Key Feature: With A.I.R.
• Manual Transmission - Column: No
• Manual Transmission - Floor: No
• Material: Mild Steel
• Port Shape: Square
• Power Steering: Yes
• Tube Design: MID-LENGTH
• Tube Diameter: 1-3/4 in.
• Tube Size: 1-3/4 in.
• Variations: 89511
• Cylinder Head Port Shape: Square
• Header Finish: HTC Polished Silver Ceramic-Metallic
• Header Material: Mild Steel
• Mounting Hardware Included: Yes
• Primary Tube Diameter (in): 1.75 in.
• Tuned: No
• Weld-Up: No
• Catalytic Converter(s) Included: No
• Crossover Pipe Included: Yes
• Crossover Pipe Style: Y-pipe
• Motor Mounts Included: No
• Quantity: Sold as a kit.
• Cylinder Head: Stock Profile Heads
• Replacement Gasket: 27680
• Installation Hardware Included: Yes
• Package Contents: Set of Headers, mounting hardware and gaskets
• with A.I.R. System: Yes
• with EGR: No
• Y-Pipe Included: Yes
• Collector Attachment: 3 in.
• Header Construction: Standard-Duty
• E.O. #: Yes
• Notes: 88-97 Ford 1/2-3/4 Ton, F150-F250-F350; 2-4WD 460 (7.5L) w/AIR
• Collector Diameter: 3 in.
• Exhaust System Dia: Factory hookup
• Reducer Outlet Size: Factory hookup
• Tube Length: Mid-Length Tubes
• Tube Style: Mid-Length
• Contents: headers, head and collector flange gaskets (when applicable), mounting hardware
• Tube Material Thickness: 16g
• Primary Tube Gauge: 16g

Extended Information:

• Country of Origin: United States
• Emissions : Released
• Life Cycle Status: Available To Order

Packing Information:

• Quantity of Each: 1
• Package UOM: ST
• Dimension: 38.000 x 18.000 x 9.000 inches
• Weight: 47.000 lb
