Hedman Hedders S10 / SB CHEVY ENGINE SWAP HEADERS 1-3/4 IN.- UNCOATED 69560

<p>Hedman Hedders has been manufacturing quality headers in the USA since 1954, and they've been manufacturing Chevy S10, GMC S15, V8 engine swap specific headers for over 20 years. Each set uses mild steel, smooth flowing, CNC mandrel bent tubes, that are hand-welded to ensure each pair is identical to the next. </p><p>These uncoated, MID-LENGTH TUBE headers are designed specifically for installing a Small Block Chevy 283-400 (Gen 1) engine into 1982-2004 Chevy S10/Blazer, GMC S15/Jimmy 2WD trucks. Fits both manual and automatic transmission trucks. The large, smooth 1-3/4 in. tube design provides excellent exhaust flow to let your transplanted 283-400 SB Chevy engine breathe easy, and produce additional horsepower and torque over factory manifolds.</p><p>These headers are uncoated, and ship from the factory with a temporary black paint that will burn off when submitted to normal operating temperatures. For protection against the element and lower underhood temperatures, these headers are also available with a silver or black ceramic-metallic finish.</p><p>Each set includes a pair of header and collector gaskets, header flange bolts and collector bolts.</p><p>Hedman Hedders is so confident in the quality of its headers that these headers are factory backed by a Limited Lifetime Warranty.</p>

• Handcrafted, Mild Steel Construction.
• The Mid-Length Tube Header Design Provides Significantly More Low and Mid-range Power than Cast Manifolds, and Provide Better Ground Clearance And Component Compatibility Than Long Tube Headers.
• Classic 3-Bolt Gasket-Style Header Collectors
• Includes All The Necessary Mounting Hardware, Gaskets and Reducers (exhaust adapters)
• Limted Lifetime Warranty On Construction, Five Year Warranty on Factory-Applied Header Coating!
• Proud To Say, Made In The USA, Since 1954!

Attributes:

• GTIN: 00732611695602
• Brand Name: Hedman Hedders
• Air Conditioning: Yes
• Finish Type: Uncoated Mild steel
• Header Style: Mid-Length Tube
• Power Steering: Yes
• Tube Design: MID-LENGTH
• Tube Size: 1-3/4 in.
• Bolts/Studs Included: Yes
• Header Material: Mild Steel
• Motor Mounts Included: No
• Contents: headers, gaskets (when applicable), 3-bolt exhaust adapters, hardware
• Notes: (Straight plug cylinder heads ONLY!)
• Exhaust System Dia: 3 in.
• Reducer Outlet Size: 3 in.
• Emissions Notes: NOT LEGAL FOR STREET USE ON '75-LATER MODEL YEARS! Legal for off-road use only.
• Engine: Chevy SB 283-400 (Gen 1) 1958-86
• Drivetrain: 2WD Only!
• Head Type: Factory Heads
• Collector Diameter: 3 in.
• Package Contents: Headers, reducers (exhaust adapters), gaskets, mounting hardware
• Tube Material Thickness: 16g
• Primary Tube Gauge: 16g
• Flange Thickness: 0.3125 in.
• Gasket Or Seal Included: Yes
• Reducers Included: Yes
• Collector Size: 3 in.
• Collector Style: 3-Bolt Gasket Style Flange
• Finish: Uncoated
• Flange Style: Standard
• Replacement Head Flange Gasket: 27560
• Header Port Shape: Square
• Material: Mild Steel
• Port Shape: Square
• Tube Diameter: 1-3/4 in.
• Tube Length: Mid-Length Tubes
• Variations: 69566
• Cylinder Head Port Shape: Square
• Header Finish: Uncoated
• Mounting Hardware Included: Yes
• Primary Tube Diameter (in): 1.75 in.
• Tuned: No
• Weld-Up: No
• Collector Bolts Included: Yes
• Catalytic Converter(s) Included: No
• Crossover Pipe Included: No
• Quantity: Sold as a pair.
• Cylinder Head: Stock Profile Heads
• Replacement Gasket: 27560
• Installation Hardware Included: Yes
• with A.I.R. System: No
• with EGR: No
• Y-Pipe Included: No
• Collector Attachment: 3 in.
• Header Construction: Standard-Duty
• E.O. #: No
• Automatic Transmission - Column: No
• Automatic Transmission - Floor: Yes
• Manual Transmission - Column: No
• Manual Transmission - Floor: Yes
• Product Details: Motor Mount Kit available. Part # 9906
• Tube Style: Mid-Length

Extended Information:

• Country of Origin: United States
• Life Cycle Status: Available To Order
• Emissions : EPA Eligible

Packing Information:

• Quantity of Each: 1
• Package UOM: ST
• Dimension: 20.250 x 13.000 x 8.000 inches
• Weight: 23.000 lb
