Hedman Hedders STANDARD UNCOATED HEADERS; 1-1/2 IN. TUBE DIA.; 2-1/2 IN. COLL.; 6-INTO-1 DESIGN 99610

<p>Hedman Hedders has been manufacturing quality headers in the USA since 1954, and they've been manufacturing Jeep headers for decades. Each set uses mild steel, smooth flowing, CNC mandrel bent tubes, that are hand-welded to ensure each pair is identical to the next. Hedman's unique, gasketless ball and socket collector design allows your exhaust system to bolt up to these Inline 6 AMC headers, even if it is not perfectly aligned with the header collectors.</p><p>These uncoated, 6-into-1, LONG-TUBE, headers fit 1972-1986 Jeep CJ5, CJ6 and CJ7 models with AMC's "torquey" 232-258 I6 engine. They are compatible with both manual and automatic transmission setups, and the long, smooth 1-1/2 in. tube design provides excellent exhaust flow to let your CJ's Inline 6 AMC engine exhale better, to pull out every bit of available torque and power you down any trail.</p><p>These headers are uncoated, and ship from the factory with a temporary black paint that will burn off when submitted to normal operating temperatures. For protection against the element and lower underhood temperatures, these headers are also available with a silver or black ceramic-metallic finish.</p><p>Each set includes a pair of gaskets, header flange bolts and collector bolts. No collector gasket is needed.</p><p>Hedman Hedders is so confident in the quality of its headers that these headers are factory backed by a Limited Lifetime Warranty.</p>

• Handcrafted, Mild Steel Construction.
• Long Tube, 6-Into-1 Header Design Provides Excellent Horsepower and Torque.
• Ball & Socket Collector Design requires No Gasket, and Allows For More Exhaust System Misalignment than Old School, Gasket-Style Header Collectors
• Includes All The Necessary Mounting Hardware, Gaskets and Reducers (exhaust adapters)
• Limted Lifetime Warranty On Construction, Five Year Warranty on Factory-Applied Header Coating!
• Proud To Say, Made In The USA, Since 1954!

Attributes:

• GTIN: 00732611996105
• Brand Name: Hedman Hedders
• Bolts/Studs Included: Yes
• Flange Thickness: 0.375 in.
• Gasket Or Seal Included: Yes
• Header Style: Long Tube
• Reducers Included: Yes
• Air Conditioning: Yes
• Automatic Transmission - Column: Yes
• Automatic Transmission - Floor: Yes
• Collector Size: 2-1/2 in.
• Collector Style: BALL and SOCKET Style (Gasketless)
• Exhaust System Dia: 2 in.
• Finish: Uncoated
• Finish Type: Uncoated Mild steel
• Flange Style: Standard
• Replacement Head Flange Gasket: 27820
• Header Port Shape: Rectangle
• Manual Transmission - Column: Yes
• Manual Transmission - Floor: Yes
• Material: Mild Steel
• Port Shape: Rectangle
• Power Steering: Yes
• Reducer Outlet Size: 2 in.
• Tube Design: 6-into-1
• Tube Diameter: 1-1/2 in.
• Tube Length: Long Tubes
• Tube Material Thickness: 14g
• Tube Size: 1-1/2 in.
• Tube Style: 6-into-1
• Variations: 99616
• Cylinder Head Port Shape: Rectangle
• Header Finish: Uncoated
• Header Material: Mild Steel
• Mounting Hardware Included: Yes
• Primary Tube Diameter (in): 1.50 in.
• Primary Tube Gauge: 14g
• Tuned: No
• Weld-Up: No
• Collector Bolts Included: Yes
• Catalytic Converter(s) Included: No
• Crossover Pipe Included: No
• Motor Mounts Included: No
• Quantity: Sold individually.
• Cylinder Head: Stock Profile Heads
• Replacement Gasket: 27820
• Installation Hardware Included: Yes
• with A.I.R. System: No
• with EGR: No
• Y-Pipe Included: No
• Collector Attachment: 2-1/2 in.
• Header Construction: Standard-Duty
• E.O. #: No
• Contents: headers, gaskets (when applicable), 3-bolt exhaust adapters, hardware
• Notes: 72-86 Jeep CJ5, CJ6, CJ7 232-258
• Emissions Notes: NOT LEGAL FOR STREET USE ON '75-LATER MODEL YEARS! Legal for off-road use only.
• Collector Diameter: 2-1/2 in.
• Package Contents: Headers, ball and socket reducers (exhaust adapters), gaskets, mounting hardware

Extended Information:

• Country of Origin: United States
• Emissions : EPA Eligible
• Life Cycle Status: Available To Order

Packing Information:

• Quantity of Each: 1
• Package UOM: ST
• Dimension: 46.000 x 20.000 x 10.000 inches
• Weight: 25.000 lb
