Hedman Hedders TIGHT TUBE MOPAR SB- BLACK MAXX 78503

<p>Hedman Hedders has been manufacturing quality headers in the USA since 1954, and classic musclecars is their specialty. Each set uses mild steel, smooth flowing, CNC mandrel bent tubes, that are hand-welded to ensure each pair is identical to the next. These headers use Hedman's patented TIGHT TUBES chamshell-style collector that allows for a low-profile header design, while still providing beneficial exhaust flow improvement over factory manifolds.</p><p>These BLACK-MAXX coated, TIGHT-TUBES headers fit a variety of 1967-1974 MOPAR passenger cars powered by Chrysler'S 273-360 LA engine (inline port port pattern only). Included in this list of popular models are 1970-74 Dodge Challenger, '67-74 Plymouth Barracuda, '66-74 Dodge Charger, '68-74 Plymouth Roadrunner 67-76 Dart, Duster, Super Bee and Valiant (check the application listings for exact fitment). The flat-style collector also makes these headers ideal for SB Chrysler equipped street rods and custom projects. These headers fit both manual and automatic transmission models, however, a mini-starter must be used, and modification to the shift linkage may be required. The smooth 1-5/8 in. tubes flow into the large, yet flat, collector, and provide improved exhaust flow, over factory manifolds, to let your Chrysler 273-360 (LA) engine produce additional horsepower and torque.</p><p>Each set includes a pair of header and collector gaskets, header flange bolts and collector bolts.</p><p>Hedman Hedders is so confident in the quality of its headers that these headers are factory backed by a Limited Lifetime Warranty. These headers have a high temperature, SATIN-BLACK ceramic finish that resists corrosion, and can withstand temperatures up to 1400 degree F. This finish is covered by a 5-year factory warranty, in addition to Hedman's standard lifetime header warranty.</p>

• The Lowest Profile Header On The Market
• The Flat, Clamshell Style Collector Has an Extremely Low Profile So they'll Fit in Nearly Any Street Rod or Custom Build With Little Clearance.
• The High Volume Flat Collector Offers Improved Exhaust Flow For Far Superior Performance Over Classic Block Hugger Models.
• Includes Classic, 3-Bolt Gasket-Style Header Collectors, Mounting Hardware, Gaskets and Reducers (exhaust adapters)
• Limted Lifetime Warranty On Construction, Five Year Warranty on Factory-Applied Header Coating!
• Proud To Say, Made In The USA, Since 1954!

Attributes:

• GTIN: 00732611785037
• Brand Name: Hedman Hedders
• Bolts/Studs Included: Yes
• Flange Thickness: 0.3125 in.
• Gasket Or Seal Included: Yes
• Header Style: TIGHT TUBES
• Reducers Included: Yes
• Air Conditioning: Yes
• Collector Size: 3 in.
• Collector Style: 3-Bolt Gasket Style Flange
• Engine Notes: MOPAR 318-360 (1967 and later LA Engines with inline port pattern only.)
• Exhaust System Dia: 2-1/2 in.
• Finish: BLACK MAXX Satin Black Ceramic-Metallic
• Finish Type: BLACK MAXX- Black Ceramic-Metallic Coating
• Flange Style: Standard
• Replacement Head Flange Gasket: 27970
• Header Port Shape: Rectangle
• Material: Mild Steel
• Port Shape: Rectangle
• Power Steering: Yes
• Reducer Outlet Size: 2-1/2 in.
• Tube Design: TIGHT TUBES
• Tube Diameter: 1-5/8 in.
• Tube Length: Tight Tubes
• Tube Size: 1-5/8 in.
• Tube Style: Tight Tubes
• Variations: 78500
• Cylinder Head Port Shape: Rectangle
• Header Finish: BLACK MAXX Satin Black Ceramic-Metallic
• Header Material: Mild Steel
• Mounting Hardware Included: Yes
• Primary Tube Diameter (in): 1.625 in.
• Tuned: No
• Weld-Up: No
• Collector Bolts Included: Yes
• Catalytic Converter(s) Included: No
• Crossover Pipe Included: No
• Motor Mounts Included: No
• Quantity: Sold as a pair.
• Cylinder Head: Stock Profile Heads
• Replacement Gasket: 27970
• Installation Hardware Included: Yes
• with A.I.R. System: No
• with EGR: No
• Y-Pipe Included: No
• Collector Attachment: 3 in.
• Header Construction: Standard-Duty
• E.O. #: No
• Transmission Notes: Modification to shifter linkage may be required.
• Automatic Transmission - Floor: Yes
• Automatic Transmission - Column: Yes
• Manual Transmission - Column: Yes
• Manual Transmission - Floor: Yes
• Contents: headers, gaskets (when applicable), 3-bolt exhaust adapters, hardware
• Notes: 66-76 Various Mopar Cars; 273-360
• Engine: Mopar SB 318-360 (inline port pattern only)
• Emissions Notes: NOT LEGAL FOR STREET USE ON '75-LATER MODEL YEARS! Legal for off-road use only.
• Collector Diameter: 3 in.
• Package Contents: Headers, reducers (exhaust adapters), gaskets, mounting hardware
• Tube Material Thickness: 16g
• Primary Tube Gauge: 16g

Extended Information:

• Country of Origin: United States
• Life Cycle Status: Available To Order
• Emissions : Released

Packing Information:

• Quantity of Each: 1
• Package UOM: ST
• Dimension: 20.000 x 13.000 x 8.500 inches
• Weight: 17.000 lb
