Jackpot LS & LS Pro EFI Hi-Rise Intake Top End Kits

The single plane Hi-Rise LS1/LS2/LS6 intake manifolds from Aces are designed for high-performance/racing and engine swap applications. Ideal for those seeking increased performance, an aggressive look, or more under-hood clearance, this carb-style EFI intake manifold enables you to generate more horsepower and torque while maintaining a classic appearance under the hood. Aces offers its hi-rise LS Intake Manifold for LS1/LS2/LS6 applications (cathedral port), available in black or natural aluminum finishes. Each kit includes a cast manifold, eight 36/65 lb/hr injectors, a 4-bbl throttle body (with MAP, IAC, and TPS sensors), anodized aluminum fuel rails with hardware and -8 AN fittings, and your choice of either a Jackpot LS or Jackpot Pro LS system, complete with all necessary harnesses and sensors for easy installation.

The 7” Pro Dash with GPS speedometer simplifies the setup process, allowing you to answer a few questions about your specific combination to achieve the perfect start-up tune. Once operational, the system's self-learn functionality monitors data and makes real-time adjustments to the calibration, removing the complexity from the tuning process. The more the vehicle is driven, the more refined the tuning becomes.

Aces' Jackpot LS stand-alone system represents the forefront of self-learning technology for GM LS-based engines. Designed to be both affordable and feature-rich, it's suitable for professional racers and hobbyists alike. The Jackpot ECU, built with Aces’ 32-bit Power Architecture®, efficiently manages input/output signals, voltage, and RPM, outperforming the competition.

For stock to mild applications, the calibration wizard and self-learning features negate the need for advanced tuning knowledge. However, for more aggressive or performance-oriented applications, Aces offers a full tuning software suite and USB data cable for manual tuning. The system is compatible with both boost and nitrous (using a separate controller) and includes a standard 2.8-bar MAP sensor.

The Jackpot™ ECU boasts dual WBO2 sensors, closed-loop fuel control, self-learning fuel and ignition control, 8 coil outputs and 8 injector drivers, dual fan control, boost compatibility, nitrous retard, and much more.

Preloaded with base maps for common LS engine combinations, the Jackpot LS system ensures a quick start, whether for casual builds or track-ready cars. Whether you're building a budget-friendly vehicle or a high-performance racing machine, Aces’ Jackpot™ EFI system offers the advanced technology and features you need in an accessible, easy-to-install package.
