Aces Fuel Injection Jackpot LS & LS Pro EFI - LS1/LS2/LS6 Tall Fabricated Intake Top End Kits AS20111-WK92-AM2026B

The Jackpot LS Fabricated Intake Top End Kits are truly Plug and Play, Easy to Install, Easy to Tune package, This kit features a fabricated intake manifold, 92mm or 102mm drive by cable throttle body or 92mm drive by wire high flow throttle body, the fuel rails, 36 lb/hr or 65lb/hr fuel injectors (8), and all the necessary harness and sensors to get your LS engine up and running easily and faster.

The 5 inch handheld with GPS speedometer allows you to answer a few simple questions about your specific combination, giving you the perfect start-up tune. Once the system is up and running, the Self-learn functionality monitors data and makes real-time changes to the calibration taking all the guesswork out of the tuning process. The more you drive, the better the learn!

If you require more advanced tuning features, ACES EFI tuning software provides an easy-to-use software suite that allows full access for advanced users (laptop required).

Application

Intake manifold will fit Cathedral Port LS1/LS2/LS6 heads,

Intake manifold is 9 inches tall

This part is legal for sale and use on Uncontrolled (Non-Emissions Controlled) Vehicles.

The following vehicles are considered Uncontrolled (Non-Emissions Controlled) Vehicles:

1965 and older U.S. manufactured California Certified vehicles

1967 and older U.S. manufactured Federally Certified vehicles

1967 and older Foreign manufactured vehicle

WARNING: It is against the law to install this part on an Emissions Controlled Vehicle

The following vehicles are considered Emissions Controlled Vehicles:

1966 and newer U.S. manufactured California Certified vehicles

1968 and newer U.S. manufactured Federally Certified vehicles

1968 and n
