PROJECT X - SERIES ONE FF.70 - FREE FORM 7 INCH LED AUXILIARY LIGHT - SPOT BEAM AL538801-1

PROJECT X - SERIES ONE FF.70 - FREE FORM 7 INCH LED AUXILIARY LIGHT - SPOT BEAM AL538801-1

PROJECT X:

Part # PROJECTX-AL538801-1
UPC # 00840005388013

$359.99 USD
$475.00 USD $359.99 USD
Sale Sold out
Shipping calculated at checkout.

Product Description

Connect with the Wild with the Project X - Series One Free Form LED auxiliary lights. The Series One utilizes enhanced free form optics to capture and focus more of the light generated from the LEDs to produce a greater penetrating light output down the road,
  • Powered by Cree - The very latest in Cree? XHP50.2 LED chip sets produce an extremely efficient yet powerful white light output (5000K)
  • Integrated Heat Management - Built-in Active Thermal Management System (ATMS) enables the FF.70 to run harder for longer
  • HID Performance in LED Package - 3,800 raw lumens (1,663 effective) per light
  • Superior Optics - Enhanced free form optics capture and focus more of the light generated from the LEDs to produce a greater penetrating light output down the road, eliminating wasted light and focusing the beam where you need it most
  • LED Front Position Light Pipe - Signature built-in LED light pipe meets ECE requirements for front position light improving daytime driving visibility and safety
  • Customizable Appearance - Customize the look of your Series One FF.70s with your choice of 2 glare shield caps in Black or Project X Green
  • Unique Fit & Adjustment - Proven heavy-duty multi-position bracket offering multiple mounting positions to guarantee the perfect fit
  • Engineered to Survive - Super strong impact resistant housing constructed from tough Fiber Reinforced Polymer
  • Protected from the Elements - Fully sealed against water and dust intrusion (IP67) utilizing integrated Deutsch? connector for a secure power connection
  • Durable Lens Design - Virtually unbreakable hard coated and UV resistant polycarbonate lens and lens protectors for rock and debris protection
  • GTIN: 00840005388013
  • Brand Name: PROJECT X
  • Add-On: AL538800-1
  • Add-On: AC538806-1
  • Add-On: AC538807-1
  • Beam Length (1 lamp)6: 1 lux @ 1443 Feet
  • Beam Length (2 lamps)7: 1 lux @ 2034 Feet
  • Beam Width (1 lamp)8: 1 lux @ 147 Feet
  • Beam Width (2 lamps)9: 1 lux @ 206 Feet
  • Bezel Color2: ?PROJECT X? Green and Black
  • Bulb Color2: White
  • Bulb Quantity1: 2
  • Bulb Technology9: LED
  • Bulb Type0: 15W XHP50.2, Cree LEDs
  • Color Rendering Index3: 70
  • Connector Gender1: Male
  • Connector Quantity2: 1
  • Effective Lumens2: 1663
  • EMC6: ECE R10
  • Hardware Included6: Yes
  • Hardware Material7: Stainless Steel
  • Heat Management4: Active Thermal Management System
  • Height.UOM6: IN
  • Height5: 7.7
  • Housing Color1: Black
  • Housing Finish3: Matte
  • Housing Material0: Fiber Reinforced Polymer
  • Input Voltage Range.UOM: V
  • Input Voltage Range: 9 - 33V DC
  • IP Rating4: IP67
  • Lamp Current Draw @ 12V: 3.32 Amps
  • Length.UOM2: IN
  • Length1: 7
  • Lens Color8: Clear
  • Lens Diameter.UOM0: IN
  • Lens Diameter9: 7
  • Lens Material7: Hard coated Polycarbonate
  • Light Beam Pattern: Spot
  • Light Color Temperature.UOM5: K
  • Light Color Temperature4: 5000
  • Light Output in Watts0: 30 Watts
  • Mounting Hole Quantity5: 1
  • Operating Temp3: -40?F to 149?F
  • Positional Light Current Draw @ 12V: 0.13 Amps
  • Protection5: Reverse Polarity Protection
  • Push or Twist Type0: Push
  • Raw Lumens1: 3800
  • Shape: Round
  • Street Legal8: Offroad Use Only
  • Terminal Gender3: Female
  • Terminal Quantity9: 1
  • Terminal Type8: Deutsch DT 3-pin
  • Total Current Draw @ 12V: 3.47 Amps
  • Universal Or Specific Fit: Universal
  • Wattage Draw @ 12V DC: Driving Light - 39 Watts, Position - 1.8 Watts
  • Wattage.UOM: W
  • Weight.UOM8: LBS
  • Weight7: 2.42
  • Width.UOM4: IN
  • Width3: 4.1
  • Wire Quantity4: 3
  • Wiring Harness Included5: Y
  • Country of Origin: Taiwan
  • Emissions : Released
  • Life Cycle Status: Available To Order
  • Quantity of Each: 1
  • Package UOM: EA
  • Dimension: 11.3100 x 9.3800 x 6.8750 inches
  • Weight: 3.9380 lb

PDF:
