PROJECT X - SERIES X HP.70 - HIGH POWER 7 INCH LED AUXILIARY LIGHT - COMBO BEAM AL538804-1
PROJECT X - SERIES X HP.70 - HIGH POWER 7 INCH LED AUXILIARY LIGHT - COMBO BEAM AL538804-1
PROJECT X:
Part #
PROJECTX-AL538804-1
UPC #
00840005388044
Regular price
$449.99 USD
Regular price
$593.00 USD
Sale price
$449.99 USD
Unit price
/
per
Product Description
Product Description
Connect with the Wild with the Project X - Series X High Power LED auxiliary lights. The Series X LED lights feature best in class performance and is engineered using Osram LED technology to cut through the darkness and light the trail ahead with a powerful combo beam. Featuring an integrated Active Thermal Management System (ATMS), the HP.70 delivers 120 watts of pure white light (5700K) in a broad penetrating beam of light.
- Unparalleled Performance - 5-Watt High Power Osram-LEDs producing 120W of pure white light (5700K)
- Integrated Heat Management - Built-in Active Thermal Management System (ATMS) enables the HP.70 to run harder for longer
- Best in Class Power - 15,000 raw lumens (8889 effective) per light
- Superior Optics - Highly Polished super-efficient aluminum metalized reflector utilizing precisely scalloped parabolas for ultimate control and performance
- LED Front Position Light - Signature built-in LED light meets ECE requirements for front position light improving daytime driving visibility and safety
- Customizable Appearance - Customize the look of your Series X HP.70s with your choice of 3 inner trim pieces, including ?Brocky? Blue, ?Dragon? Red and ?Project X? Green.
- Unique Fit & Adjustment - Tool free vertical adjustment allows on-the-fly beam correction via ergonomic adjuster knob. The mounting system utilizes polyurethane bushings to suspend the light making it impervious to shock and vibration.
- Engineered to Survive - Constructed from light weight super strong Pressure Die Cast Aluminum, uncompromised strength and rugged durability
- Protected from the Elements - Fully sealed against water and dust intrusion (IP66 & IP67) utilizing a genuine Gore-Tex? breather vent and integrated Deutsch? connectors
- Durable Lens Design - Virtually unbreakable hard coated and UV resistant polycarbonate lens and lens protectors for rock and debris protection
Attributes
Attributes
- GTIN: 00840005388044
- Brand Name: PROJECT X
- Add-On: AC538810-1
- Add-On: AC538811-1
- Beam Length (1 lamp)6: 1 lux @ 1886 Feet
- Beam Length (2 lamps)7: 1 lux @ 2664 Feet
- Beam Width (1 lamp)8: 1 lux @ 147 Feet
- Beam Width (2 lamps)9: 1 lux @ 206 Feet
- Bezel Color3: ?Brocky? Blue, ?Dragon? Red and ?PROJECT X? Green
- Bulb Color2: White
- Bulb Quantity1: 24
- Bulb Technology9: LED
- Bulb Type0: Osram LEDs
- Color Rendering Index3: 72
- Connector Gender1: Male
- Connector Quantity2: 1
- Effective Lumens2: 8889
- EMC6: ECE R10
- Hardware Included6: Yes
- Hardware Material7: Stainless Steel
- Heat Management4: Active Thermal Management System
- Height.UOM6: IN
- Height5: 7.8
- Housing Color1: Black
- Housing Finish2: Powder Coat
- Housing Material0: Pressure die-cast aluminum
- Input Voltage Range.UOM: V
- Input Voltage Range: 9 - 33V DC
- IP Rating4: IP66 & IP67
- Lamp Current Draw @ 12V: 8.77 Amps
- Length.UOM2: IN
- Length1: 7
- Lens Color8: Clear
- Lens Diameter.UOM0: IN
- Lens Diameter9: 7
- Lens Material7: Hard coated Polycarbonate
- Light Beam Pattern: Combo
- Light Color Temperature.UOM5: K
- Light Color Temperature4: 5700
- Light Output in Watts0: 120 Watts
- Mounting Hole Quantity5: 3
- Operating Temp3: -40?F to 149?F
- Positional Light Current Draw @ 12V: 0.17 Amps
- Protection5: Reverse Polarity Protection
- Push or Twist Type0: Push
- Raw Lumens1: 15000
- Shape: Round
- Street Legal8: Offroad Use Only
- Terminal Gender3: Female
- Terminal Quantity9: 1
- Terminal Type8: Deutsch DT 3-pin
- Total Current Draw @ 12V: 9 Amps
- Universal Or Specific Fit: Universal
- Wattage Draw @ 12V DC: Driving Light - 106 Watts, Position - 2.2 Watts
- Wattage.UOM: W
- Weight.UOM8: LBS
- Weight7: 3.85
- Width.UOM4: IN
- Width3: 4
- Wire Quantity4: 3
- Wiring Harness Included5: Y
Extended Information
Extended Information
- Country of Origin: Taiwan
- Emissions : Released
- Life Cycle Status: Available To Order
Packing Information
Packing Information
- Quantity of Each: 1
- Package UOM: EA
- Dimension: 11.3800 x 10.8800 x 7.1300 inches
- Weight: 6.5164 lb
