Speed Warrior™ Intake Manifold

Weiand is no stranger to the performance aftermarket. Since the 1930s, Weiand has been delivering serious performance parts to street /strip enthusiasts, marine customers and hard core racers. Times have changed as bigger motors, higher RPMs, better ignition systems and ultra efficient cylinder head designs have generated a need for better manifold technology. Weiand has delivered! *** Utilizes late model alternator an A/C bracket mounting provisions. Has additional vacuum tap off of runner. Recommended intake manifold gasket - Mr Gasket #'s 5821 or 101G. Plenum depth: From the carb flange to the bottom of the upper plenum is 2-3/16". To the bottom of the lower plenum is 4-1/16".

• Precision CNC Machining
• High Rise/Dual Plane Design
• Square Bore Carburetor Flange
• Exhst Crossover For Improved Street Drivability (Std. SBC Heads)
• 1500-6700 RPM Power Band
• Height Front 4.19 in.; Rear 5.27 in.
• Port Size 1.92 in. Height x 1.16 in. Width

Attributes:

• GTIN: 00090127631355
• Brand Name: Weiand
• Barrel: Four
• Cylinder Head Type: Standard
• Emission: Without EGR
• Engine Make/Size: Chevy Small Block V8
• Finish: Shiny
• Front Height: 4.190 in.
• Fuel System Type: Carbureted
• Manifold Type: High Rise
• Number of Carbs: One
• Position: Lower
• Rear Height: 5.270 in.
• RPM Range: 1500-6700
• Usage: Street/Strip
• WARNING CA Proposition 65: No

Extended Information:

• Country of Origin: China
• Emissions : Electronically Announced
• Life Cycle Status: Available To Order

Packing Information:

• Quantity of Each:
• Package UOM:
• Dimension: 25.0000 x 12.1000 x 7.0000 inches
• Weight: 14.5500 lb
